Technical Information
Sharing knowledge is our Mission. Our experience has been achieved by the many projects and tasks that we have put our hand to. To keep it to ourself and not share the passion for RF is be grossly wrong. Our door is always open to those who want to learn more about this fascinating field of technology. These guides are totally free to you.
How to manufacture a Phasing Harness for stacking of antenna.
From time to time there is the requirement to manufacture an Antenna Phasing Harness. Typically to save the trouble, we purchase these however they are frequency sensitive so have to be specially ordered. Here you can make your own and we will tell you how. The equipment we use is either the Anritsu S332E or the RigExpert MATCH. These units are available for purchase from Electrotest.
How to match 2 lengths of RF cable.
At times we need to ensure lengths of RF cable are equal in length. Due to the Velocity Factor, the physical and electrical length will not be the same due to the propagation through the medium. Following this process, you can ensure that these lengths are exactly matched in electrical length. The equipment used is either the Anritsu S332E or the RigExpert MATCH. These units are available for purchase from Electrotest.
How to adjust a Tuned Circuit using the RigExpert MATCH
Manufacturing tuned circuits and antenna traps can be made simple and easy when using the RigExpert MATCH or similar Tester.
Following this process, you can ensure that these lengths are exactly matched in electrical length. The equipment used is either the Anritsu S332E or the RigExpert MATCH. These units are available for purchase from Electrotest.
